Simer 3985C Manuel D'installation, D'utilisation Et D'entretien

293 Wright Street • Delavan, WI 53115
SAFETY INFORMATION
Carefully read and follow all safety instructions in this
manual and on pump.
This is the safety alert symbol. When you see this
symbol on your pump or in this manual, look for one of
the following signal words and be alert to the potential for
personal injury!
warns about hazards that will cause serious
personal injury, death or major property damage if ignored.
warns about hazards that can cause serious
personal injury, death or major property damage if ignored.
warns about hazards that will or can cause
minor personal injury or property damage if ignored.
The word NOTICE indicates special instructions which are
important but not related to hazards.
1. Read these rules and instructions carefully. Failure
to follow them could cause serious bodily injury and/or
property damage.
2. Check your local codes before installing. You must
comply with their rules.
Hazardous voltage. Can shock, burn or
kill. During operation the pump is in water. To avoid fatal
shocks, proceed as follows if pump needs servicing:
3. Disconnect power to outlet box before unplugging pump.
4. Unplug the pump before handling or servicing.
5. Take extreme care when changing fuses. Do not stand
in water or put your finger in the fuse socket.
6. Do not modify the cord and plug. When using the cord
and plug, plug into a grounded outlet only. When wiring
to a system control, connect the pump ground lead to
the system ground.
7. Do not run the pump dry. Dry running can overheat the
pump (causing burns to anyone handling it), and will
void the warranty.
8. The pump normally runs hot. To avoid burns when
servicing pump, allow it to cool for 20 minutes after
shut-down before handling it.
9. The pump is permanently lubricated. No oiling or
greasing is required in normal operation.
10. Do not install the basin and pump in any location
classified as hazardous by the United States National
Electrical Code (NEC), or by the Canadian Electrical
Code (CEC), where applicable.
© 2013
InStallatIon, operatIon, & partS Manual
Preplumbed Sump Pump System
PUMP SPECIFICATIONS
Power Supply Required ..................................... 115V, 60 Hz
Individual Branch Circuit Required ..........................15 Amps
Maximum Liquid Temperature .......................... 120°F (50°C)
Discharge Adapter .............................................. 1-1/2" NPT
DESCRIPTION
The Simer Sump Pump System, is ideal for basement and
cellar installations. It includes a submersible sump pump
and a corrosion-resistant sump basin and lid. The pump
features a flush-mount system for maximum discharge of
the basin. All components of the sump pump system are
pre-assembled at the factory for easy installation.
This submersible pump is designed for sump drainage,
dewatering and flood control. The pump has built-in thermal
overload protection and an automatic reset. The mechanical
seal and sleeve bearings on the motor shaft are permanently
lubricated.
This system is designed for residential use only. The
supplied hardware kit includes a rubber inlet hub and a
cord grommet. No special tools or sealants are required.
NOTICE: This system is not designed for applications involving
salt water or brine! Use with salt water or brine will void
warranty.
PERFORMANCE
GPH (LPH) AT TOTAL FEET (METERS) OF LIFT
Model 5 (1.5 m) 10 (3 m)
2,220
3985C
(8,404)
*For performance at maximum temperature see Catalog.
15 (4.6 m) 20 (6.1 m)
1,800 1,260 300
(6,814) (4,770) (1,136)
SIM820 (10/17/13)
No flow
at height
shown
below
23 ft
(7.0 m)
