For the assembly of the shower tray (version B and C), a concrete floor or a styrofoam carriers can be used.
Please pay attention to the manufacturer's specifications. Load capacity of a minimum 250 kg/m² should be
guaranteed.
■
Walls must be vertikal.
■
For constructional reasons in case of frameless shower enclosures absolute waterproofness is not possible.
For the safety reasons this device should not be used by physically and mentally disabled people (and children) or by
people without relevant experience or knowledge, unless they use it, under supervision of relevant persons or get the
instruction how to use it.
Children should use this product only under adult's supervision.
⚠
Attention: due to high temperature within the working area of steam jet and at steam outlet, direct skin
contact should be avoided.
- warning! Hot surface!
⚠
Silicone must be provided by building constructor. Please keep in mind that maintenance joints may
require cleaning.
02
Equipment
■
Back walls in white made of toughened safety glass with EverClean coating.
■
Frameless glazing on the front made of toughened safety glass (6 mm) with an EverClean coating
■
Roof, made of glass (6 mm).
■
Shower tray (optionally) made of mineral cast Incl. pre-assembled frame
■
Integrated control panel
■
Steam generator with automatic rinse and decalcification. Nominal voltage 230 V, 50/60 Hz
3.3 kW for the rectangular version 1000x1000, 1200x1000, quarter circle and square version 1000x1000
4.0 kW* for the rectangular version 1400x1000, 1600x1000, 1800x1000
■
Steam jet with a condensate drip tray
■
Functional column made of aluminium, two functional columns on the rectangular version 1600x1000,
1800x1000
■
Fittings (chrome-plated) consisting of (per functional column):
Hand shower, rain shower (15 l/min), 6 adjustable back jets (6 x 3 l/min), thermosat 1/2˝, 2 shut-off valves
(left functional column), 3 shut-off valves (right functional column).
■
Rain shower and back jets electronically operated
■
Sound Module: Bluetooth, Radio, 2 speakers
■
LED-stripe with colour changer in the roof frame
■
A stool made of stainless steel with PU seat, for the rectangular version 1600x1000 and 1800x1000 two stools
■
Glass frame joints with lifting mechanism
02.01 Fittings technical data
■
Recommended flow pressure:
■
Hot water temperature:
■
Recommended hot water temperature: 60-70°C
■
Temperature range:
■
Safety cut-off:
*
3,3 kW for Switzerland
200-500 kPa
max. 90°C
20-60°C
38°C
GB
13
