Door Panels for Dispenser Models
The two freezer panels combined SHOULD NOT WEIGH more
than 30 lbs. (13.5 kg). The refrigerator panel SHOULD NOT
WEIGH more than 50 lbs. (23 kg).
A
23 7 /
16
(60 cm)
34 7 /
16
(87 cm)
Model A
36 in. (91 cm) 14¹⁄₄ in. (36 cm)
42 in. (106 cm) 16³⁄₄ in. (43 cm)
48 in. (122 cm) 19¹⁄₄ in. (49 cm)
Top Grille Panel – Routing Requirements
Top and bottom edges of the top panel should be edge routed
¹⁄₂ in. (1.3 cm) and ³⁄₈ in. (9.5 mm), respectively. Both ends should
be edge routed ⁷⁄₈ in. (2.2 cm) as shown.
1 / "
4
(6 mm)
max.
Top
Grille
7 / "
8
(2.2 cm)
12
B
"
70 / "
7
16
(179 cm)
"
B
19¹⁄₄ in. (49 cm)
22³⁄₄ in. (58 cm)
26¹⁄₄ in. (67 cm)
Top
Grille
7 / "
8
(2.2 cm)
NOTE: When creating a panel with face detail, the offsets will be
hidden and must be accounted for in order to center the detail in
the top grille.
(1.3 cm)
Center face
detail between
(9.5 mm)
Door Panels – Routing Requirements
If an extended handle kit is used, then routing the handle side of
the panels is not required. See "Classic Series Factory Panels
and Kits" for more information on ordering extended handles.
If the standard handle is used, route the entire handle side of both
panels 3¹⁄₄ in. (8.25 cm) to allow for finger clearance. Then route
the other sides 1 in. (2.54 cm).
Standard Handle – Top View
3
(8.25 cm)
min.
1 / " (6 mm) max.
4
1 / "
4
(6 mm)
max.
Door Panel - Side View
1 /
4
(6 mm) max.
1 / "
2
min.
offsets
3
/ "
8
min.
1 /
4
(6 mm) max.
1 / "
4
Door
Panel
2" (5 cm)
min.
1 /
4
(6 mm)
max.
1
/ " (1.3 cm)
2
min.
"
"
Hinge Side
Door
Panel
1"
(2.54 cm)
"
