1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new tool brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability
laws, the manufacturer of this device assumes no
liability for damage to the device or caused by the
device arising from:
• Improper handling
• Failure to comply with the operating manual,
• Repairs carried out by third parties, unauthorised
specialists.
• Installing and replacing non-original spare parts,
• Improper use
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regu-
lations and VDE regulations 0100, DIN 57113 /
VDE0113.
Note:
Read the whole text of the operating manual before
assembly and commissioning.
This operating manual should help you to familiarise
yourself with your device and to use it for its intended
purpose.
The operating instructions contain important informa-
tion on how to operate the machine safely, profes-
sionally and economically, how to avoid danger, cost-
ly repairs, reduce downtimes and how to increase
reliability and service life of the machine.
In addition to the safety instructions in this operating
manual, you must also observe the regulations ap-
plicable to the operation of the device in your country.
Keep the operating manual at the device, in a plastic
sleeve, protected from dirt and moisture. They must
be read and carefully observed by all operating per-
sonnel before starting the work.
The device may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards. The required
minimum age must be observed.
In addition to the safety instructions in this operating
manual and the separate regulations of your coun-
try, the generally recognised technical rules relating
to the operation of such machines must also be ob-
served.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58

2. Device description (fig. 1-16)

1. Blow-off device
2. Holder (Blow-off device)
3. Knurled screw
4. Holder (Saw blade guard)
5. Saw blade guard
6. Saw table
7. Fine-wire fuse
8. Cover, left
9. Storage box
10. Bearings
11. Tightening lever
12. Support
13. Graduated scale
14. Knurled nut
15. Suction connection
16. On/off switch
17. Stroke rate controller
18. Assembly points (rubber feet pre-assembled)
19. Work lamp
20. ON / OFF switch work lamp
21. Saw blade
22. Allen key, 3 mm
23. Depressor
24. Screw (depressor)
25. Table inlay
26. Saw blade holder, top
27. Upper saw blade clamping screw
28. Lower saw blade clamping screw
29. Saw blade holder, bottom
30. Angle (not included in the scope of delivery)
31. Screw (Pointer degree scale)
32. Pointer
33. Screw (left cover - front)
34. Screw (left cover - rear)
35. Adjustment screw with locknut

3. Scope of delivery

• Scroll saw
• Saw blade guard (5) with depressor (23)
• Blow-off device (1)
• Saw blade (21) for wood and plastics (2x) (1x pre-
assembled)
• Allen key, 3 mm (22)
• Operating Manual

4. Proper use

The fretsaw was designed to cut square-edged tim-
ber or other workpieces such as Plexiglas, glass fiber
reinforced plastic, foam, rubber, leather, and cork. Do
not use this saw to cut round materials. Round mate-
rials can easily become jammed.
