1. Activate logging function
Allows activation or deactivation of event logging for KAPIRIS III.
Activate this function by clicking "External alarm input" on the view web page, then select "Apply."
2. Wiring for auxiliary input:
Polarization principle for auxiliary input:
Input polarized
Input not polarized

9.2 Automatic deactivation of the MW sensor

The MW sensor can be automatically deactivated when the detection zone is disturbed by the
ambient environment (Ex.: vegetation in the MW detection zone, by hard rain, etc.)
Such deactivation occurs after an automatic adjustment of the sensor threshold. If the disturbances
generate ambient noise greater than the adjusted threshold then the sensor is deactivated.
It automatically reactivates itself after a time delay of 10 minutes.
This function works only in detection mode and if the PIR sensor is not off.
Automatic deactivation of MW
External switch
12
+ Auxiliary
11
- Auxiliary
External alarm function
Alarm input off
Alarm input on
Activate logging function
Network not
connected
Logging deactivated
Logging activated
- 50 -
KAPIRIS III
+
Power
12V DC exterior
-
Network connected
Not used
Not used
