If no alarm is triggered in the detection zone, do the following:
 Adjust the orientation of the sensor
 Then adjust the sensitivity.
Adjust from 1 (low sensitivity) to 10 (very sensitive)
Check to be sure that the PIR sensor does not detect beyond the established zone by making
passages outside this zone.
Ex: For a zone established for 20m, pass by at a distance of 30m. If the passage is detected, the
sensor's position must be changed.
Before blocking the KAPIRIS III sensor, turn switch 1 to OFF to deactivate the buzzer. Tighten the
adjustment screw to secure the orientation of the sensor.
Tightening the sensor with a 6 mm Allen
key
Be careful not to strike the MW
sensor with a screw driver or other
tool to avoid damaging it.
