CONNECTION

7.1 User PC configuration

By default, the connection parameters of KAPIRIS III are as follows:
IP address
Subnet mask
The following procedure allows for the configuration and connection of the user's PC to KAPIRIS III.
Under WINDOWS* XP:
 Go to Control Panel , double-click on Network connections , then on Local Area Connection
and select Properties .
 In General tab, Highlight the line Internet Protocol (TCP/IP) , then click on Properties .
 Choose the option Use the following IP address and enter the network settings below.
Under WINDOWS* 7:
 Go to Control Panel , double-click on Network and Sharing Center , then left select Change
adapter settings , then click on Local Area Connection .
 In Networking tab, Highlight the line Internet Protocol Version 4 (TCP/IPv4) , then click on
Properties.
 Choose the option Use the following IP address and enter the network settings below.
Network settings:
Parameters
IP address
Subnet mask
192.168.105.202
255.255.255.0
Value
192.168.105.XX
255.255.255.0
- 37 -
Notes
The last number must be comprised
between 1 and 254 (different from 202)
Mandatory value
