Installation Instructions
6. SECURE THE CASE IN THE
WINDOW AND INSTALL THE
FOAM TOP WINDOW GASKET
CAUTION
To prevent broken glass or
damage to windows, on vinyl or other similarly
constructed windows, attach the window
locking bracket to the window side jamb.
Vinyl
A. Attach the window locking bracket with one Type
C screw.
B. Cut the foam top window gasket to the window
width.
C. Stuff the foam between the glass and the window
to prevent air and insects from getting into the
room.
NOTE: If the gasket supplied does not fit your
window, obtain appropriate material locally to
provide a proper installation seal.
7. INSTALL THE AIR
CONDITIONER IN THE CASE
A. Slide the air conditioner into the case by
the base pan. Do not push on the controls,
styrofoam air discharge housing or the finned
coils. Make sure the air conditioner is firmly
seated.
Base Pan
12
7. INSTALL THE AIR
CONDITIONER IN THE CASE
B. Replace the 2 screws removed earlier, one on
IMPORTANT: THE GROUND SCREWS MUST BE
REINSTALLED TO ENSURE PROPER GOUND.
Wood
C. Attach the front grille to the case by inserting the
D. Replace the screws.
E. Install the filter and the front grille.
Do not press on
these areas—
damage to the unit
may result
F. Plug in the air conditioner.
each side of the case.
tabs on the grille into the slots on the front top of
the case. Push the grille in.
(CONT)
