7. MAINTENANCE AND PRESERVATION
Correct maintenance is essential to maintain the
o r iginal efficency and safety of the machine over
time.
WARNING!
During maintenance ope­
ra tions:
– remove the spark plug cap.
– Wait until the engine is sufficiently cold.
– Use protective gloves when handling the
bla des.
– Keep the blade protection devices on, ex­
cept when intervening directly on the blade.
– Never dispose of oils, fuel or other polluting
materials in unauthorised places
CLEANING THE ENGINE AND THE SILENCER
To reduce fire risks, periodically clean the cylinder
flaps with compressed air and clear the si len cer
area from branches, leaves or other de bris.
CLEANING THE AIR FILTER
IMPORTANT
Cleaning the air filter is es­
sen tial to guarantee the efficiency and duration of
the machine.
It must be cleaned after every 8-10 working hours.
To clean the filter (Fig. 8):
– Loosen the knob (1) remove the cover (2) and
the filter element (3).
– Wash the filter element (3) with soap and wa ter.
Do not use petrol or other solvents.
– Leave the filter to dry in the open air.
– Refit the filter element (3) and close the cover (2)
pushing until it clicks into place.
FUEL FILTER
Inside the fuel tank there is a filter which prevents
impurities from entering the engine.
The filter should be replaced once a year by your
Re tailer.
All manuals and user guides at all-guides.com
CHECKING THE SPARK PLUG
Periodically, remove and clean the spark plug from
any eventual deposits using a metal brush.
Check and reset the correct distance between the
electrodes (Fig. 9).
Replace the spark plug and fasten it firmly using
the supplied key.
The spark plug must be replaced with one with
the same characteristics in the cases where the
electrodes have burnt or the insulation has worn
out, and in any case every 50 working hours.
TUNING THE CARBURETTOR
The carburettor is tuned by the manufacturer to
achieve maximum performance in all situations
of use, with a minimum emission of toxic gas in
compliance with current specifications.
In the case of poor performance, first check that
the blades are not partially blocked or deformed,
on the contrary ask your Retailer to check the car-
burettor and the engine.
• Tuning minimum speed
not move when the engine is running idle. If
the cutting device moves when the engine is
running idle, contact your dealer to correctly
regulate the engine.
LUBRICATING THE REDUCTION GEAR
(Fig. 10)
Every 20 working hours, top up the level with spe-
cial molybdenum bisulphur lubrication, in jec ting it
into the lubricator (1).
BLADE CLEANING AND CHECK
blades are not bent or deformed and that the
screws are adequately tightened.
Adjustment of the distance between blades is not
necessary, as this is predetermined by the ma-
nufacturer.
MAINTENANCE AND PRESERVATION
WARNING!
The cutting device must
WARNING!
Periodically check that the
