STANDARD EQUIPMENT:
BATTERY
ENGINE
TRANSAXLE
TRANSMISSION
FUEL TANK
BRAKES
PARKING BRAKE
FRONT SUSPENSION
REAR SUSPENSION
STEERING
STEERING WHEEL
SEATING
SEATING CAPACITY
TOTAL LOAD CAPACITY
SPEED
CHASSIS
BODY
STANDARD COLORS
DASH PANEL
LIGHTING/HORN
TIRES
TIRE PRESSURE
WEIGHT (Without Fuel)
OPERATING CONTROLS &
INSTRUMENTATION
FEATURES
WARNING (Europe Only): This is a Class A product. In a domestic environment, this product may cause radio interference, in which
case the user may be required to take adequate measures.
OPTIONS/ACCESSORIES:
2 Bag Attachment
4 Bag Attachment
4 Caddy Kit
Accent Stripes
Ash Tray
Bag Cover
Basket, Side
Bunker Rake with Holder
CE Package
Cooler Jug (No Side Basket)
Divot Repair (Sand Container & Scoop Requires Side Basket)
Divot Repair (Sand Bottle, No Side Basket)
Full Sound Control Package
Hour Meter
All manuals and user guides at all-guides.com
TXT GASOLINE - FREEDOM™ LE
One 12 Volt Maintenance Free (430 CCA, 60 Minute Reserve)
9 hp (6.7 kW) 18 ci (295 cc) Twin Cylinder, Air Cooled, Overhead Cam, Overhead Valve
Pressurized Lubrication with Washable, Permanent Oil Filter
Internal Balance Shaft
Solid State Ignition with RPM Limiter
Replaceable Dry Cartridge Air Filter
Fixed Jet Bowl Carburetor, Pulse Fuel Pump
13.32:1 Helical Geared with Neutral Lock & Ground Speed Governor
Automatic Continuously Variable Transmission (CVT)
6 Gallon (23 Liters) Tank, 36 lbs. (16 kg) Fuel Weight
Dual Rear Wheel, Self-Adjusting Mechanical Drum Brakes
Automatic Parking Brake Release with Self-Compensating System
Leaf Springs with Hydraulic Shock Absorbers
Leaf Springs with Hydraulic Shock Absorbers
Single Reduction Rack & Pinion
Dual Handgrips, Pencil Holder & Scorecard Holder
Cushion Foam/Vinyl Cover, Hip Restraint/Hand Hold
Operator & 1 Passenger
800 lbs. (360 kg) Including Operator, Passenger, Accessories & Cargo
15 mph (23 kph)
Welded Tubular Steel; Powder Coated (DuraShield™)
Flexible, Impact Resistant DuraShield™ Injection Molded TPE (Thermoplastic Elastomer)
with Base Coat/Clear Coat
Champagne/Hunter Green/Cloud Gray/Bright Silver Metallic/Flame Red/Dark Garnet/Patriot Blue
Pearl/Black/Steel Blue Pearl
Wood Grain with 4 Drink Holders
Single Halogen Light Bar, Tail & Brake Lights, Horn
18 x 8.00 - 10 (4 Ply Rated) Load Range B
20 - 25 psi (140 - 170 kPa)
679 lbs. (308 kg)
Removable Key, 'Deadman' Accelerator Control, Direction Selector, Audible Reverse Warning,
Analog Fuel Gauge, Low Oil Pressure Indicator
Sun Top, Fold Down Windshield, Center Basket, Turn Signal with 4-Way Flasher, Wood Grain
Locking Glove Box Doors
Owner's Manual and Service Guide
GENERAL SPECIFICATIONS
Key Switch (Custom)
Key Switch (Individually Keyed)
Long Fender Liners
Message Holder
Paint Color (Custom)
Powertrain (High Altitude 3000-6000 ft)
Powertrain (High Altitude 6000-10000 ft)
Rear View Mirror (Requires Top)
Sand Bottle Kit
Seating (Special Color)
Tow Bar (Detachable)
Tow Bar (Permanent)
Weather Protection Enclosure
Windshield One-Piece (Top Required)
Windshield Rear
