Anwendungshinweise
Mit diesem Prüfgerät kann die Zaunspannung an jeder
beliebigen Stelle der Zaunanlage oder auch die Ausgangs-
spannung direkt am Weidezaungerät gemessen werden. Es
werden Spannungsimpulse zwischen 200 und 9.900 Volt
erfasst. Spannungsimpulse über 10.000 Volt werden mit
"HI" angezeigt.
Das Prüfgerät wird mit einer 9 Volt-Batterie gespeist (im
Lieferumfang enthalten) und schaltet sich selbständig "Ein"
und "Aus".
Fig. 1)
Zur Messung wird das Gerät zwischen Erde (Erdspieß) und
Zaun (Kontaktöse) geschaltet.
Sannungswerte > 2.000 Volt sind nach VDE als sicher zu
bewerten. Je höher die Spannungswerte, umso sicherer ar-
beitet die Anlage.
Hohe Spannungen und energiereiche Impulse erfordern ei-
nen besonders spannungsfesten Zaunaufbau. Eisenpfähle
haben hierbei keine Einsatzberechtigung mehr, allenfalls
i.V.m. besonderen Isolatoren.
Bewuchs und Überschläge an Isolatoren und Eisenpfählen
reißen die Spannung nach "unten". Somit streigt der Strom-
verbrauch und es wird eine Spannung am Erdpfahl messbar
sein.
Fig. 2)
Spannung am Erdpfahl
Starke zum Erdpfahl rückfließende Ströme erzeugen hier
eine spürbare Schrittspannung am Erdwiderstand.
ACHTUNG: Ist am Erdpfahl eine Spannung zu messen, so
sind
1. Abflüsse in der Zaunanlage vorhanden und
2. die Erdleitfähigkeit in Nähe der Erdpfähle könnte besser
sein (mehrere Erdstäbe in feuchten Grund schlagen)
Also: Bei Spannung am Erdpfahl sind Ableitungen am Zaun
zu beseitigen und die Erdung ist zu verbesssern !
Fig. 3)
Durchschlagende Isolatoren an Eisenpfählen können eben-
falls ermittelt werden. Derjenige Pfahl mit keiner oder der
niedrigsten Anzeige ist der Übeltäter. Das Übersprüngen des
Funkens arbeitet wie eine Spannungsbegrenzung.
Die Spannungspotentiale an beiden Messpunkten sind fast
gleich, so das wir keinen oder nur einen geringen Span-
nungswert erhalten.
ranger Fence Voltmeter Digital
EN
Application Tips
The fence voltage can be measured from any position on
the fencing system and can be used to measure the output
voltage directly from the electric fencing unit. Voltage pulses
between 200 and 9,900 volts can be measured. Voltage
pulses over 10,000 are indicated with "HI".
The tester works with a 9 volt battery (included in delivery)
and switches itself on and off.
Fig. 1)
To use the tester place it between the earth (earth post) and
fence (contact ear)
According to VDE voltage results >2000 volts are consi-
dered safe. The higher the voltage the more effective the
fencing system.
High voltages and impulses rich in energy, demand a special
voltage resistant constructed fence. Here iron posts should
not be used, only in conjuction with special insulators.
Arking on insulators and iron posts causes the voltage to
go down. Therefore the power consumption rises and some
voltage will go to earth.
Fig. 2)
Voltage to the earth post
Here, heavy currents which flow back to the earth post pro-
duce at the earth resistance a noticeable voltage working
in steps.
ATTENTION: If voltage can be measured at the earth post,
there are
1. drains in the fencing system and
2. the earth conductivity near the earth posts could be bet-
ter (drill several earth posts into humid ground)
Therefore: In case of voltage at the earth post one has to
elimate the conductance at the fence and the grounding has
to be improved !
Fig. 3)
Damaged isolators on iron posts can also be found. The post
with none or with the lowest indication is damaged. The ar-
king of the spark works as a voltage limitation. The voltage
potentials at both measuring points is almost equal so that
you get none or only low voltage data.
