ASTRALPOOL CDP LINE V2
FRIGORIFIC CIRCUIT
© ASTRALPOOL 2015 ALL RIGHTS RESERVED. PROPRIETARY DOCUMENT
All manuals and user guides at all-guides.com
N⁰ DESCRIPTION
Hi/Low pressure valves
Compressor
Compressor
Compressor
Compressor
Filter
Expansion valve
Port
Port
Port
Port
Hi Pressure mini switch
Low pressure mini switch
MODEL
All
2
3
4
5
All
All
2
3
4
5
All
All
.
ANNEX
CODE MAT.
65891R029
65891R030
65892R001
65893R003
65894R002
65891R031
65891R032
65891R033
65892R002
65893R004
65894R003
65891R034
65891R035
