ASSEMBLY AND SETUP
GB
9. Connect the smaller 3/8 I.D. drain to the drain port Z on the cutter deck motor.
10. Left hand Wing Deck (as viewed from operators seat):
a) Attach straight end of the 5/8 I.D. hose W from the cutter deck motor return port (has a 90
one end) to the return tube X on the tractor.
b) Connect the end of the remaining 5/8 I.D. hose to the
FRONT OF TRACTOR
á
11. Connect the smaller 3/8 I.D. drain to the drain port Z on the cutter deck motor.
12. Be sure hoses do not rub on tractor when raising or lowering cutter decks.
13. Make sure all tractor tyre pressures are set to 14 psi. (1 kg/cm
shipping. Cutter deck tyres are foam filled.
14. Check battery electrolyte level and charge. Use protective equipment such as, but not limited to,
goggles, face shield, rubber gloves, and apron.
15. Before starting the machine:
–
Fill the fuel tank with Diesel fuel.
–
Check and top up the engine sump with engine oil if needed.
–
Check and top up the radiator with a 50% antifreeze solution if needed.
–
Check and top up the hydraulic system with oil.
–
Check all points for lubrication (refer to the lubrication section in this manual).
–
Acquaint yourself with the instructions at the beginning of this manual, paying particular attention
to the control and operation sections.
GB-16
RANSOMES Frontline 951 Plus
OPERATORS MANUAL
(PRESSURE) tube Y on the tractor.
REAR OF TRACTOR ä
2 ). Tyres may be overinflated for
o fitting on
