BluGuitar REMOTE 1 Mode D'emploi page 20

The following functions are available when the Direct-Access-Mode is active (the Mode/Store switch is lit):
CLEAN, VINTAGE, CLASSIC, MODERN, BOOST, REVERB, FX-LOOP, adjustable 2nd Master Volume and PowerSoak.
These are additional functions for the AMP1 ™ that are not available without the REMOTE1 ™ .
Using the switches 1 - 4, you can choose between the four patches, CLEAN, VINTAGE, CLASSIC, and MODERN. They can only be used one
5 (BOOST) activates the AMP1
at a time because only one of the four channels can be active. Switch ™ 's adjustable Boost. Switch
turns the adjustable Hall effect on or off, and Switch 7 activates and deactivates the FX-LOOP for the AMP1 ™ . The two extra functions that
are accessed with Switches 8 (2nd Master Volume) and 9 (PowerSoak), can be adjusted with the Level Control knob which is situated
between the two switches.
LEVEL
MASTER
Setting the 2nd Master Setting the Gain / Clean Volume
When Switch 8 is activated and lit, the Level Control knob next to it Press and hold the BOOST switch for approximately 2 seconds, until it
blinks. Now use the Level Control on the REMOTE1
can be used to reduce the 2nd Master Volume as much as 10dB.
The 2nd Master Volume level is automatically stored when Switch 8 is (as long as one of the overdrive channels, VINTAGE, CLASSIC, or
deactivated, and can be recalled by activating Switch 8 again. MODERN is activated), or the Clean Volume (as long as the clean
channel is activated). As with the 2nd Master Volume, the Gain can only
Setting the PowerSoak be reduced using the Level Control knob, with results depending upon
Activate the PowerSoak with Switch 9. The Switch is lit. Set the required how the Gain and/or Clean Volume contols are set on the AMP1
reduction with the Level Conrol knob. therefore recommended to set the AMP1 ™ to maximum gain, and use
the Level Control on the REMOTE1 ™ to achieve the required amount
of Gain when storing a preset.
1 2 3 4
Setting the Looperkit
Press and hold the FX-Loop switch until it blinks. Switches 1 - 4 operate
the loops. Use Mode/Store to store.
Press and hold FX LOOP
until the switch blinks:
set Loops 1 - 4
6 ( REVERB )
™ to set the Gain
™ . It is
GAIN:
Press and Hold BOOST until
the switch blinks:
set the Gain
OPeratiNG
Mode Selection:
Direct Access Mode: switch is unlit
Preset Mode: switch is lit blue
Preset-Mode offers the ability to combine all of the REMOTE1 ™ control and switching functions available in Direct-Access-Mode into
complete and individual sounds that can each be stored as one of 36 available presets. This lets you call up your own, signature sounds on
stage at the push of a button. REMOTE1 ™ offers you 4 banks with 9 presets each. Press the Mode/Store switch to access the Preset-
Mode. When the switch is lit, Preset-Mode is active. 9 different sounds can be stored in each of the banks, and directly accessed using the
switches 1 - 9.
Switching Banks
Press and hold the Mode/Store switch (when lit) until it blinks. The
switch for the currently active bank will be lit, and the other 3 will blink.
Select another bank by pressing one of the blinking switches. The Mode/
Store switch will stop blinking and the new bank is active. 9 presets in
the now active bank can be accessed using switches 1 - 9.
It was a deliberate decision to create a board with 9 presets and „only"
four banks. For one thing, it is still pretty easy to keep track of 9 presets
per bank, and most guitar players are quite well served with 9 sounds
in a live situation. And there are another 3 banks that can be loaded
with 9 more presets each. This way you can set up a bank that fits each
of your bands, your projects, in your living room, or just to experiment.
If you require more than 36 presets, you still have the option of making
the AMP1 ™ MIDI compatible with the help of the BluGuitar ® MIDI-
Adapter (optional). Controlled by an external MIDI pedal, the MIDI
standard allows for 128 presets.
Changing Banks:
Press and hold MODE/STORE until it blinks: when turned off, REMOTE1 ™ stores all current settings automatically . when power is restored, the last settings are again active.
Use switches 1 - 4 to select a bank
Programming Sound Presets
To program specific sounds that you can later recall in Preset-Mode,
you first need to switch to Direct-Access-Mode. Press Mode/Store
switch until it is no longer lit. Now you can create the sound you want
to program using the pedal functions and Level-Controller on the
REMOTE1 ™ . To store the sound to a specific preset location, press and
hold the Mode/Store switch for 2 seconds, until switches 1 through 9
are blinking. Pressing one of the nine blinking switches will permanently
store your newly created sound to that location, and the switch will be lit.
Having stored your sound, the REMOTE1 ™ automatically switches back
to Preset-Mode, recognizable by the now lit Mode/Store switch.
To program a new preset, switch to the Direct-Access-Mode by press-
ing the Mode/Store switch again. Following the steps described above,
you can now create a new sound and store it to another preset.
