Remove the trimmer head
1. Remove the battery.
2. Press the 2 release tabs on the
spool retainer to remove it
(see Fig. 11& 12).
3. Pull the spring out of the spool base
(Fig. 16).
4. Rotate the spool base to align the
slot in the flange with the hole in the
gear case (Fig. 17).
5. Insert the hex wrench provided
into the aligned holes to act as a
stabilizer (Fig. 18). Use the multi-
function wrench provided to loosen
the nut in the direction of the arrow
marked on the spool base inside
housing and remove it (Fig. 19).
16
Spool Base
17
Gear Case
18
19
STRING TRIMMER ATTACHMENT—STA1500
Nut
Spring
Aligned Shaft-locking Holes
Spool Base
Stabilizer
Arrow
Multi-function
Wrench Provided
23
