CONNECTING THE STRING TRIMMER ATTACHMENT TO THE POWER HEAD
WARNING:
running or with the battery installed. Failure to stop the motor and remove the battery
may cause serious personal injury.
This string trimmer attachment is designed for use with EGO Power Head PH1400.
The string trimmer attachment connects to the power head by means of a coupler device.
1. Stop the motor and remove the battery pack.
2. Loosen the wing knob.
3. Remove the end cap from the string trimmer attachment. Align the arrow on the
string-trimmer shaft with the arrow on the coupler and push the string-trimmer
shaft into the coupler until you hear a clear "click" sound, which indicates that the
string-trimmer shaft is mounted into place (Fig. 4).
4. Pull the shaft of the attachment to verify that it is securely locked into the coupler.
If not, rotate the string-trimmer shaft from side to side in the coupler until it snaps
into place.
5. Tighten the wing knob securely.
WARNING:
equipment; check it periodically for tightness during use to avoid serious personal injury.
4
String-Trimmer Shaft
REMOVING THE ATTACHMENT FROM THE POWER HEAD
1. Stop the motor and remove the battery pack.
2. Loosen the wing knob.
3. Press the shaft-release button and, with the button depressed, pull or twist the
attachment shaft out of the coupler.
Never attach or adjust any attachment while the power head is
Be certain that the wing knob is fully tightened before operating the
Wing Knob
STRING TRIMMER ATTACHMENT—STA1500
Arrow on the Coupler
Arrow on the Attachment Shaft
Power Head Shaft
Shaft-Release Button
