AL-KO Service
For repairs, we offer our customers a comprehensive net-
work of AL-KO service stations throughout Europe.
A list of service stations can be obtained directly from us;
the order number is 371912

Maintenance

Clean ball coupling
Grease or oil ball socket, joints and bearings.
„
Lubricant type:
„
multi-purpose grease according to
„
ISO-L-XCCHB3

Troubleshooting

Fault
coupling does not click
into place after laying on
the tow bar
trailer can not be un-
coupled
too mutch play between
coupling and tow ball
For faults not listed in this table, or which you cannot resolve by yourself, please contact our customer service.

Disposal

Do not dispose of old equipment, batteries or accumulators as household waste!
Packaging, machine and accessories are manufactured using recyclable materials and must be disposed
of accordingly.
1361617_f
Possible cause
ball diameter greater than Ø50mm
insufficient drawbar load
interior parts of the coupling soiled
Ice and snow
tow ball out of truel
detent pawl not pressed
ball coupling worn
swivel range exceeded
rivet bent
Maintenancepoints (
7):
1 Oil point
2 Lubrication point

Repairs

Caution!

Repairs may be performed only by qualified tech-
nicians.
Replacement parts are safety parts!
We recommend using only original AL-KO re-
placement parts or parts expressly approved by
us.For the certain identif cation of replace-ment
parts, our service stations need the replacement
part identif cation number (ETI).
Solution
have tow ball changed
press the ball coupling downwards manually
clean coupling and grease, replace if
necessary
put trailer and car in the same direction of
travel and uncouple
grease or oil coupling mechanism
press detent pawl
have ball coupling replaced
rivent straighten
