Torque Values
Metric Fasteners (DIN)
TORQUE VALUES (Based on Bolt Size and Hardness)
8.8
Size Nm ft.lb.
M3 1.2 *11
M4 2.9 *26
M5 6.0 *53
M6 10 7
M8 25 18
M10 49 36
M12 86 63
M14 135 99
M16 210 155
M18 290 214
M20 410 302
1 ft.lb. = 1.357 Nm
10.9
Nm ft.lb. Nm
1.6 *14 2.1
4.1 *36 4.9
8.5 6 10
14 10 17
35 26 41
69 51 83
120 88 145
190 140 230
295 217 355
405 298 485
580 427 690
* = in.lb.
WRENCH SIZE
12.9
ft.lb. Metric Inch
*19 5.5 7/32
*43 7 9/32
7 8 5/16
13 10
30 13
61 17 11/16
107 19
169 22
262 24 15/16
357 27 1-1/16
508 30 1-1/4
1 inch = 25.4 mm
Torque Values
Metric Inch
2.5 –
3 –
4 –
– 5 –
1/2 6 –
8 –
3/4 10 –
7/8 12 –
14 –
14 –
17 –
