English
Replacing the Saw Chain (Fig. A, H)
CAUTION: Sharp chain. Always wear protective
gloves when handling the chain. The chain is sharp
and can cut you when it is not running.
WARNING: Sharp moving chain. To prevent
accidental operation, ensure that battery is removed
from the tool before performing the following
operations. Failure to do this could result in serious
personal injury.
•
Flip up locking tab and rotate the bar adjust locking
knob (
8
) counterclockwise to release chain tension.
•
Remove sprocket cover (
Guide Bar and Saw Chain section.
•
Lift the worn saw chain (
guide bar (
4
) .
•
Place the new chain in the slot of the guide bar, making
sure the saw teeth are facing the correct direction by
matching the arrow on the chain with the graphic on
the sprocket cover (
6
•
Follow instructions for Installing the Guide Bar and
Saw Chain.
Fig. H
Replacement chain and bar are available from your
nearest D
WALT service center.
e
•
DCCS670 requires replacement chain # DWRC1600,
service part number 90618541. Replacement 16" bar,
service part number 90618542.
Saw Chain and Guide Bar Oiling (Fig. I)
Auto Oiling System
This chain saw is equipped with an auto oiling system that
keeps the saw chain and guide bar constantly lubricated.
The oil level indicator (
10
chain saw. If the oil level is less than a quarter full, remove
the battery from the chain saw and refill with the correct
type of oil. Always empty oil tank when finished cutting.
nOTE: Use a high quality bar and chain oil for proper chain
and bar lubrication. As a temporary substitute, a non-
detergent SAE30 weight motor oil can be used. The use of
a vegetable based bar and chain oil is recommended when
pruning trees. Mineral oil is not recommended because it
may harm trees. Never use waste oil or very thick oil. These
may damage your chainsaw.
Filling the Oil Reservoir
•
Flip down locking lever and unscrew counterclockwise
a quarter turn and then remove the oil cap (
12
) as described in Installing the
6
5
) out of the groove in the
) shown in Figure H.
) shows the level of the oil in the
16
the reservoir with the recommended bar and chain oil
until the oil level has reached the top of the oil level
indicator (
•
Refit the oil cap and tighten clockwise a quarter turn.
Flip up locking lever to its locked position.
•
Periodically switch the chain saw off and check the oil
level indicator to ensure the bar and chain are being
properly oiled.
Fig. L
10
Transporting Saw (Fig. A, J)
•
Always remove the battery from the tool and cover the
guide bar (
transporting the saw.
•
Engage chain brake by pushing chain brake / front hand
guard (
3
Fig. J
OPERATION
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start-up can cause injury.
Installing and Removing the Battery Pack
(Fig. K, L)
nOTE: For best results, make sure your battery pack is
fully charged.
To install the battery pack
battery pack with the rails inside the tool's handle and slide
it into the handle until the battery pack is firmly seated in
the tool and ensure that it does not disengage.
To remove the battery pack from the tool, press the release
button
?
and firmly pull the battery pack out of the tool
handle. Insert it into the charger as described in the charger
section of this manual.
) . Fill
10
) .
4
) with the scabbard (
11
) forward.
?
into the tool handle, align the
16
) (see Figure J) when
