2610051954.qxp_OS50VC 8/16/18 12:47 PM Page 11
FIG. 11
DUST
PORT
TRIGGER "ON-OFF" SWITCH
To turn the tool "ON" squeeze the trigger
switch. To turn the tool "OFF", release the
trigger switch, which is spring loaded and will
return to the "OFF" position automatically
(Fig. 1).
See START OF SANDING on page 12.
"LOCK-ON" BUTTON
The "Lock-ON" button, located near the trigger
allows for continuous operation at maximum
OPM without holding the trigger (Fig. 1).
TO LOCK TRIGGER "ON": squeeze trigger,
depress button and release trigger.
TO UNLOCK THE TRIGGER: squeeze trigger
and release it without depressing the "Lock-
ON" button.
depressed, the trigger can not be released.
VARIABLE SPEED DIAL
Your sander is equipped with a variable speed
dial (Fig. 1). The sander's orbital speed can be
preset by rotating the dial to any of six
positions from 1 (8000 OPM) to 6 (11000
OPM).
In general,
• Higher-speeds are used to achieve results
VX120
Operating Instructions
If the "Lock-ON" button is
continuously
being
BOSCH VH-
SERIES HOSE
BOSCH VAC-
SERIES HOSE
1-1/2" HOSE
VAC024
SUCTION CONTROL
SLOT
more quickly.
• Lower speeds are especially appropriate
when sanding soft materials or thin veneers
to minimize the possibility of over sanding.
The best results will be obtained by sanding a
test sample of the workpiece material and
determining the best combination of sanding
speed and sanding sheet (sanding paper).
FRONT HANDLE
Your sander is equipped with a removable
front handle when sanding in tight quarters. To
remove handle, remove screw with 5 mm hex
wrench. Always reinstall handle for normal
operation (Fig. 1).
Depending on the task, you may grip the rear
handle alone, the rear handle and the front
handle, or the rear handle and the top of the
ergonomically contoured soft grip motor
housing, which is designed for that purpose.
ABRASIVE SHEETS (SANDPAPER)
Aluminum oxide, silicon carbide, or other
synthetic abrasives are recommended for
power sanding use. Natural abrasives, such as
flint or garnet sheet are too soft for economical
use in power sanding. For best results, use
Bosch abrasive sheets: The uniform spacing
between grains minimizes filling or loading.
The high quality aluminum oxide sheet with
-11-
1-1/4"
OR
