below. Close the paper compartment. Keep the button (43) pressed for manual
paper feed. Connect the charger (44) and USB lead (45) to the printer and
charge the printer. To print stored results of the fl ushing and test programs,
plug the USB lead (45) into the USB port (Fig. 2 (33)). After selecting the memory
manager, press Enter, the printer switches on automatically. Select the Display/
Print menu item, select the fi le no. Press Enter to print the data shown on the
screen. Press the the button (43) twice to switch off the pusher. The connection
to the USB line (45) or charger (44) must be disconnected. The following printer
functions are indicated with the LED (41).
LED fl ashes repeatedly once: printer ready for operation.
LED fl ashes repeatedly twice: overheating
LED fl ashes repeatedly 3 times: low paper
LED fl ashes repeatedly 4 times: unsuitable charger
3.9 Operation of compressed air tools
Compressed air tools can be operated up to a max. air requirement of 230 Nl/min
can be operated directly from the compressed air vessel. The air pressure
supplied by the compressed air vessel can be checked on the compressed air
vessel pressure gauge (Fig. 4 (30)). The compressor can be switched off at
any time with the compressor emergency stop button (Fig. 4 (29)). The adjusting
wheel must be raised to set the pressure of compressed air tools (Fig. 4 (31)).
The set pressure can be read at the compressed air tools pressure gauge
(Fig. 4 (32)).
3.10 Transport and storage
Drain REMS Multi-Push, REMS V-Jet TW, REMS V-Jet H as well as all hoses
completely to avoid damage; store dry at ≥ 5°C. Residue water from pressure
testing with water, fl ushing, disinfection, cleaning and preservation should be
removed with the connecting hose compressor/water connections (Fig. 8 (38))
after every use. This is connected to the compressed air tools connection on
one side (Fig. 4 (28)) and respectively to the fl ushing supply (Fig. 1 (14)) or the
pressure test with water supply on the other side (Fig. 1 (24)). See 3.9 for the
further procedure.
Protect REMS Peroxi Color, REMS CleanH and REMS NoCor against frost,
heat and direct sunlight. Keep containers tightly closed and store in a cool,
well-aired place.
The water connections on the device and the hoses should be sealed by caps
or plugs to prevent contamination.
4 Maintenance
Notwithstanding the maintenance described below, it is recommended to send
in the power tool to an authorised REMS contract customer service workshop
for inspection and periodic testing of electrical devices at least once a year. In
Germany, such periodic testing of electrical devices should be performed in
accordance with DIN VDE 0701-0702 and also prescribed for mobile electrical
equipment according to the accident prevention rules DGUV, regulation 3
"Electrical Systems and Equipment". In addition, the respective national safety
provisions, rules and regulations valid for the application site must be considered
and observed.
4.1 Inspection
WARNING WARNING
Pull out the mains plug before inspection!
Check hoses and seals for damage before every use. Replace damaged hoses
and seals. Keep all the hose connections clean. Remove residue water from
fl ushing, disinfection, cleaning, preservation or from pressure testing with water
5 Fault
NOTICE NOTICE
If faults occur, fi rst check whether the respective latest version software (Ver. Software) is installed on the input and control unit. Select the Settings menu and then
Device data to display the version software. The latest version software (Ver. Software) for the input and control unit is available by USB stick as a download under
www.rems.de → Downloads → Software. Compare the number of the version software with the latest version software number and install the latest version software
on the input and control unit by means of a USB stick if necessary. See 2.3 for the further procedure.
If the REMS Multi-Push welcome message remains constant in the control panel (Fig. 1 (36)) or if the Error message is displayed in any program on the control
panel (36), the power supply of REMS Multi-Push should be interrupted by pulling out the mains plug or pressing the RESET button (2) and switched back on
according to 2.1 Electrical Connection. If Error is displayed again, the procedure must be repeated after pressure in the REMS Multi-Push has been relieved.
To do this, pull out the mains plug, close the water pipe and remove all the hoses, caps and stoppers from the REMS Multi-Push, then switch back on according
to 2.1 Electrical Connection of Machine.
5.1 Fault: REMS Multi-Push does not switch on after pressing the On/Off button (4).
Cause:
● On/Off button (Fig. 2 (4)) pressed too briefl y.
● PRCD fault current circuit breaker (Fig. 1 (1)) is not switched on.
● Mains lead/PRCD defective.
● REMS Multi-Push defective.
30
after every use with the connecting hose compressor/water connections (Fig.
8 (38)). Seal machine connections and hose ends with caps or plugs. Flush
the REMS V-Jet TW disinfection unit or REMS V-Jet H cleaning and preserva-
tion unit (Fig. 7), without bottle (Fig. 7 (21)), with fresh water after every use.
Keep all the hose connections clean. Open both condensation screw plugs
from time to time (Fig. 1 (34)) to drain condensation from the compressed air
tank (Fig. 1 (35)), especially necessary when working at low temperatures;
observe storage temperature for unit of ≥ 5°C (1.3).
Empty the tank of the condensation and particle fi lter (Fig. 4 (46)) in the elec-
tronic fl ushing and pressure testing unit with compressor regularly. The fi lter
cartridge must be cleaned and replaced if necessary. On machines manufactured
before April 2018, the protective hood (Fig. 1 (37)) must be removed to empty
and clean the condensation and particle fi lter. Loosen the 6 screws of the
protective hood (Fig. 1 (37)) for this. Clean the air fi lter of the compressor
regularly.
Change the fi ne fi lter cartridge (Art. No. 043054) of the fi ne fi lter (Art. No.
115609) regularly.
In order to ensure that the date and time remain saved at all times, the button
cell (Lithium CR1220, 3 V) on the back of the operating panel (Fig. 1 (36))
should be changed about every two years. Loosen the 6 screws of the protec-
tive hood (Fig. 1 (37)) to do this, remove the protective hood. Then loosen the
4 screws of the operating panel and change the button cell on the back of the
operating panel.
Clean the machine regularly especially when it has not been in use for a long
time. Clean plastic parts (e.g. housing) only with REMS CleanM machine cleaner
(Art. No. 140119) or a mild soap and a damp cloth. Do not use household
cleaners. These often contain chemicals which can damage the plastic parts.
Never use petrol, turpentine, thinner or similar products for cleaning.
Make sure that liquids cannot get inside the electronic fl ushing and pressure
testing unit with compressor.
4.2 Pressure gauge calibration
Calibration of the control elements (pressure sensors) of the REMS Multi-Push
is not necessary. It is recommended to check the pressure gauge every 2 years.
To do this, the pressures shown in the display can be checked by additionally
connecting an accurate, fi nely scaled pressure gauge (see Accessories 1.2)
between REMS Multi-Push and the installation. You must make sure here that
the pressure of the stress test is not applied to the fi nely scaled pressure gauge
up to 250 mbar, otherwise it will be destroyed.
The pressures displayed on the screen of the REMS Multi-Push can be calibrated
at the REMS-ROLLER Service Center if necessary. A test certifi cate is issued
for the calibration. Calibration of the external pressure gauge for the pressurised
vessel (30) and the compressed air tools (32) is not necessary.
4.3 Inspection / Repair
WARNING WARNING
Pull out the mains plug before carrying out maintenance or repair work!
This work may only be performed by qualifi ed personnel.
Remedy:
● Press On/Off button for about 2 s, then release.
● Switch on PRCD fault current circuit breaker as described in 2.1..
● Have the mains lead/PRCD changed by qualifi ed personnel or an authorised
REMS customer service workshop.
● Have the REMS Multi-Push checked/repaired by an authorised REMS
customer service workshop.
