BADU Eco Motion Fiche Technique page 40

Electrical installation
Power cable must be
connected to Terminals
L and N at
single-phase supply
Auxiliary voltage
24V Safety
enable contacts
Digital input for fixed
speed control
Analouge input for
external speed control
WG27.50.080-2-P
EN 40
L
U
V
-
W
N
PTC
PE
Power section
20
24 V
21
S1
22
S2
Control circuit
50
24V
24V 50
In11 51
In12 52
In13 53
In14 54
In15
55
56
In16
59
DGND
61
Aln11
62
Aln12
AGND 69
Display
M
3~
A
GND
RS485
+24V
B
A1
NC
B1
COM Relais 1
C1
NO
A2
NC
B2
Relais 2
COM
C2
NO
A
GND
RS485
+24V
B
A11
NC
B11
COM Relais 11
C11
NO
A12
NC
B12
Relais 12
COM
C12
NO
06|2017
