As soon as the RDNET CONTROL 2 unit is turned on, all devices will be
listed and cyclically scanned ("polling").
Every listed device confirms its state by turning its LINK LED on.
10 times a second, each device is checked in a single daisy-chain and
(when required) the current state is sent to the PC software.
Run the software (in Windows: Start > Programs > RCF Group > RDNet
> RDNet).
lt appears the main window with 7 menus:
FILE - SYNOPTIC - OPTIONS - VIEW - MODE - ADVANCED - ?
FILE
Exit: RDNET software quit.
Save: it saves the current configuration as a file (groups
and equalizations included).
Load: it loads a configuration previously saved as a file.
New: new configuration.
LOAD AND NEW SELECTIONS DELETE
THE CURRENT CONFIGURATION'.
Load skin: it loads a software skin.
SYNOPTIC
Add Object: a sliding menu opens on the left, a list of all
RDNET supported appliances.
This menu allows appliances to be added to mimic diagram
in Offline mode (when the connection between PC and HUB
is inactive and no diffuser is detected on the network).
To add an appliance, select the sub-network where the
appliance is to be added to ("line") from pop-up menu
and double click on appliance itself. In normal operation,
appliances registered by RDNET network automatically
appear in the mimic diagram without using the "Add
Object" function.
Delete Selection: it deletes (after confirming) the selected
object.
Locked: if enabled (tick), it locks the position of all modules
on the mimic diagram.
RDNET
SOFTWARE USE
