Length of base module: 2450 mm per drive section.
Length of additional module: 2000 mm
Depth: 890 mm.
Height: 1650 mm.
- Net weight
• single-fronted version: --- kg.
• double-fronted version: --- kg.
• single-fronted version: 230 kg
• single-fronted additional module: 175 kg

STANDARD EQUIPMENT

950329015A Beam mounting bracket (2)
950331770 Foot plate (4)
950345915 Support plate (2)
950420839 Spring 17x32x0.8 (1 per head)

OPTIONAL ACCESSORIES

807246329 Axial motion for drive section
807247885 Axial motion for additional element

NORMAL OPERATING CONDITIONS

The equipment is intended for professional use only.
CAUTION!
Get to know your machine: your familiarity with its exact operation is the best guar-
antee of safety and performance.
Learn the set up of all controls and their functions.
Accurately check for correct functioning of every machine control device.
To prevent accidents and personal injury, all the equipment must be correctly installed,
correctly operated and correctly serviced.
The BR-AP/AP-S winder is designed exclusively for the production of packages, using the
instruments supplied as described in this manual.
ATTENTION
Any use of the machine other than the described use is to be considered as improper
and unreasonable.
ATTENTION
It is advisable to use only CORGHI original tools for the work.
Fig. 5 shows correct operator position during loading and unloading of the cones.
