GRMF SERIES GAS FRYERS
5. Drain the oil from the fry tank by turning the drain valve handle. The filter pan
will begin to fill with oil. Once the tank is drained, pull the red handled FILTER
lever towards you. See Fig 6. The motor / pump will begin and oil will flow
back into the fry tank. The oil will flow into the back of the tank towards the front
and then back down into the filter pan.
6. After a minute, close the drain valve turning off the flow of oil into the filter pan. The fry tank
will begin to fill. It is normal to see air bubbles in the tank when the filter pan is emptied. The
motor / pump sound will change when the filter pan is empty of oil which is normal. Push in
the red FILTER handle lever to turn off motor/pump.
7. Press the FILTER switch to the OFF position. Turn the Gas lever to the ON position. Fig. 5a.
8. The oil level is correct when it is between the Min / Max lines on the fry tank. Add new oil if
necessary.
9. Turn the Thermostat knob to the desired temperature. Burners should turn on and the oil
should begin to heat.
10. Repeat this procedure for the remaining tank(s) in the battery.
11. When finished filtering and the filter assembly has cooled down to room temperature, clean
all of the filter components as in step 1 under Assembly section on page 17.

FILTERING TIP:

Open the filtering drawer approximately 1" to allow any oil in the return line to run back into the filter
pan. This will take about 30 seconds to complete. Then open the drawer completely to clean filter
components.

REMOVING EXCESS DEBRIS FROM THE FILTER:

1. Pull the filter drawer out.
2. Remove the filter screen assembly. Scrape debris from the filter screen. Then remove the
insert by unlatching the latch. Clean all parts thoroughly as mentioned in the Assembly
section on page 17.
3. Scrape debris from the bottom of the filter pan and discard in the trash. Clean all parts
thoroughly as mentioned in the Assembly section on page 17. Clean all parts thoroughly as
mentioned in the Assembly section on page 17.
4. Reassemble all filter components after being dried thoroughly as in the Assembly section on
page 17.
VULCAN-HART
-21-
Fig. 6
F-31233 Rev. T (12-15)
