3. Attach mounting bracket to solid surface with hardware (not provided).
POST MOUNT WITH BRACKET (PROVIDED)
GROUND
MOUNTING WITH BANDING TECHNIQUE
Photoelectric Sensor
27.5" maximum
above grade
GROUND
DIRECT MOUNT (WITHOUT BRACKET PROVIDED)
Hardware
(Not provided)
Hardware
(Not provided)
27.5" maximum
above grade
Photoelectric Sensor
27.5"
maximum
above grade
GROUND
WALL MOUNT WITH BRACKET (PROVIDED)
GROUND
Refl ector
27.5" maximum
above grade
GROUND
Hardware
(Not provided)
6
Hardware
(Not provided)
27.5" maximum
above grade
Refl ector
27.5"
maximum
above grade
GROUND
