GIMA SpA
If after having acknowledged the shown impedance the value of this it increases relatively to the acknowledged value according
to the followings increases:
for acknowledged impedance <20
for acknowledged impedance between 20
for acknowledged impedance > 100
the equipment prevents the delivery of current, it indicates the OC condition and shows the new value of impedance.
4.3.3 S
C
TORING OF
ONDITION OF
Using the section STORED DATA it is possible to store 9 different operational conditions and levels of output power (program
0 is the default one).
To store the parameters it is enough to perform the following procedure:
Press the key SELECT to find the number of the program that you want to use.
Press the key STORE to store the parameters.
To recall the stored data it is enough to perform the following procedure:
Press the key SELECT to find the number of program that you want to recall. Press the key RECALL to recall the
parameters.
For modify a program it is enough to select the same program and to perform the procedure of storing once more.
4.4 PRESELECTION OF THE DELIVERABLE CURRENT
The deliverable current for the surgical operations can have pre-selected through push button at the side of sections CUT and
COAG. The power of the level for any functions can be pre-selected through the buttons + e – of the sections CUT e COAG.
The selected power's levels remain memorized.
4.4.1 C
C
UT AND
OAGULATED
The best current for the cut is the pure sinusoidal wave without modulation that means with duty-cycle 100%.
Such current, proper for cut without coagulation, it can be moderately modulated for getting cut with different degrees of
coagulation.
The degree of modulation can be varied, among the values 100% and 70% of duty cycle in four steps, by choosing
the duty-cycle of the delivered current, through the push button SELECT and checking the value gotten through the
up led tip.
Naturally the degree of coagulation increases when the duty cycle value decreases.
4.4.2 M
C
IXED
The mixed current (BLEND) it is suited for coagulated cut when a deep coagulation together the cut is desired. This current is
made by sine current suited or the cut associated to low voltage current suited for coagulation (soft coag). With this, a MIXING
current suited for cut coagulated in absence of eschar and carbonization is obtained, particularly suitable for endoscopic surgery.
4.4.3 B
C
C
IPOLAR
UT
URRENT
This current is high voltage pure sine current and suited for cut without coagulation either monopolar or bipolar. The use of
bipolar forceps it is allowed only with this current. To allow the connection of the cable bipolar forceps it is necessary the use of
an adapter that prevents any other type of current from delivering. (see figure page 31)
Manuale d'istruzioni / Instruction's Manual
value + 30
and 100
value + 50%
U
SE
C
(CUT)
UT
(BLEND)
URRENT
(BIPOLAR CUT)
MA182IGBb
value + 60
DIATERMO MB200
28
