WARNING
!
To avoid possible fire or shock, do not pinch wires
between the hanger ball/downrod assembly and
hanger bracket.
4.2
Carefully lift the Fan and seat the Hanger Ball/
Downrod Assembly on the Hanger Bracket that was
just attached to the Outlet Box (Figure 14).
Be sure the Groove in the Ball is engaged with the
Anti-Rotation Tab on the Hanger Bracket (Figure 14).
WARNING
!
Failure to seat tab in groove could cause damage to
electrical wires and possible shock or fire hazard.
NOTE: CEILING COVER, SUPPL Y WIRES AND FAN WIRES
OMITTED FOR CLARITY.
Figure 14
Please contact 1-800-654-3545 for further assistance
11
OUTLET
BOX
HANGER
BRACKET
HANGER BALL/
DOWNROD
ASSEMBLY
HANGER BALL
HANGER BRACKET
HANGER BALL
GROOVE
ANTI-ROTATION
TAB
emersonfans.com
U.L. Model No.: CF765-1
