2.6 ASSEMBLY OF THE DISPERSION CONE*
(MOdULAr MOdELS)
This device distributes the ice in the silos, and avoids ice compression
under the exit pipe.
Changing its position, the ice could be directed to any direction.
*NOT INCLUDED

2.7 WATER LEVEL

The function of the water level is to maintain the necessary flow on the evaporator, and using the
magnetic micro device incorporated, stop the operation of the machine until the water reaches
again the container. The models 400, 550 and 1100 have a water pressostat replacing the micro-
magnetic.
The optimum level is located on the horizontal indicated in the figure, and its regulation is made
following the indications appearing below.
PROBE
SAFETY OVERFILL
FLOAT VALVE REGULATION
FLOAT
Turn upwards to increase the level,
and downwards to decrease it.
(Grab from the metallic arm, NEVER
FROM THE FLOAT)
