- 17 -
Important notes
Safety instructions
-
Protect the unit against moisture, dirt and
damage during transport, storage and
operation.
-
Do not operate the unit outside the
specified technical data.
-
Operate only in a closed housing
(distribution cabinet).
-
Earth the unit at the terminals provided
for this purpose.
-
Do not obstruct cooling of the units.

Technical data

Connection
For fibre-optic patch
cables (2x50 / 125 µm)
Transmission
ST jack
Reception
ST jack
ABB i-bus
®
EIB
Bus connection
terminal
Dimensions
90 x 72 x 64 mm
(H x W x D)
Weight
0.300 kg
- 21 -
- 18 -
Technical data
The purpose of the unit is to link two sections
of an ABB i-bus EIB line by means of fibre-
optic cables in order to bridge large distances
and/or to avoid lightning and voltage surge
protection equipment when cables are being
installed between buildings.
Two units are required to set up a
transmission line. They are connected to an
existing fibre-optic cable system by means
of a 2-metre patch cable. Two fibre-optic
cables that are suitable for the transmission
of 850 nm signals transmit the signals. Direct
connection using appropriately finished
standard cables is also possible. An SV/S
30.640 voltage supply system needs to be
provided in both EIB sections.
Start-up/operation
It is not necessary to enter a physical address
or to set parameters.
- 22 -
- 19 -
Technical data
Power supply
Via ABB i-bus
®
EIB
Inputs/outputs
1 ST transmitter
1 ST receiver
Transmission line
Max. line loss
Total 14 dB at 850 nm
Max. line length
(examples)
With 50/125 µm fibres
(4 dB/km) about 3.5 km
With 200 µm fibres
(10 dB/km) about
1.4 km
Installation
For installation in distributors. Quick
attachment to 35 mm mounting rail (DIN EN
50022).
The bus connection is established by
attaching the bus connection terminal (is
supplied with the module).
The inputs/outputs are connected by means
of the patch cable (2 metres long) that is
supplied. The smallest bending radius of the
patch cable is 60 mm.
- 23 -
- 20 -
Technical data
Control - display elements
LED
(yellow)
Data are being
transmitted
LED
(yellow)
Data are being
received
Sign holder
LED and pushbutton No function
Protection rating
IP 20 in accordance
with DIN 40050
Protection category
II
Operating
temperature range
- 5 to 45° C
- 24 -
