Endress+Hauser Proservo NMS5 Manuel De Mise En Service page 7

Proservo NMS5
Endress+Hauser
PROSERVO NMS53
Order code
Ser. no.
Input rated
Input
Output
Relay contact rated
30 V AC, 2A; 42 V DC, 2A, 60 W.
Measuring range
Ambient temperature
Manufacturing date
XP Class I, Div. 1, Gp. C, D
F M
XP Class I, Zone 1, Gp. IIB
DIP Class II, III, Div. 1, Gp. E, F, G
APPROVED
Temperarure Class T4
Ambient temperature: -20
Warning: Keep cover tight while circuits are alive.
Caution: Use supply wires suitable for 70
Caution: A seal shall be installed within 50 mm of the enclosure.
Endress+Hauser Yamanashi Co.,Ltd.
Yamanashi 406-0846
Figure 3 : Agrément FM type XP
PROSERVO NMS53
Order code
Ser. no.
Input rated
Input
Output
Relay contact rated
30 V AC, 2A; 42 V DC, 2A, 60 W.
Measuring range
Ambient temperature
Manufacturing date
XP-AIS Class I, Div. 1, Gp. C, D
F M
XP-AIS Class I, Zone 1, Gp. IIB
DIP Class II, III, Div. 1, Gp. E, F, G
APPROVED
XP-ANI Class I, Div. 2, Gp. C, D
Temperarure class T4
Ambient temperature: -20
Warning: Keep cover tight while circuits are alive.
Caution : Use supply wires suitable for 70
Caution : A seal shall be installed within 50 mm of the enclosure.
Install: per drawing Ex421-439-
Endress+Hauser Yamanashi Co.,Ltd.
Yamanashi 406-0846
Figure 4 : Agrément FM type XP-AIS
Désignation du modèle
Référence de commande
Numéro de série
Alimentation
Entrée signal
Sortie signal
m
-20 ~ +60
+60 NEMA 4X, IP67
minimum .
Made in Japan
NP-2346-4
m
-20 ~ +60
+60
minimum .
Made in Japan
NP-2421-5
2 Identification
Désignation du modèle
de commande
Référence
Numéro de série
Alimentation
Entrée signal
Sortie signal
Numéro de version XA
7
