BTL5-A/C/E1_ -M _ _ _ _ -SF-F _ _
Micropulse Transducer - Rod Style
7
Accessories (continued)
7.4

Welded port AD-XA-003-D38, 1-5

50.5
34.8
38.1
Fig. 7-5: BAM AD-XA-003-D38, 1-5
Material: Stainless steel 1.4435 BN2 (Fe < 0.5 %)
acc. to EN 10088
Ordering code: BAM01A3
Mounting
surface
Fig. 7-6: Installing the BTL
www.balluff.com
Welded port
Fig. 7-7:
Fig. 7-8:
Welded flush on the inside and polished
Welded non-flush on the inside and polished
