Note : steps 2 to 4 are not necessary if the default identity code group on delivery (01)
is preserved.
1
Open the housing of the transmitter
2
Press button S1, the
Press function button
The number of the identity code group currently used by the transmitter is replicated by the
2 indicator lights :
3
RED indicator light
GREEN indicator light
The code group number is incremented each time button
then n°1 etc...
4
Validate the identity code group by pressing button
Compose a code using the 8-cursor DIP_switch :
5
6
Close the housing of the transmitter
By default (in the delivery) the transmitter identity code is :
[GROUP 1] + [ON - ON - ON - ON - ON - ON - ON - ON]
Orion - 324501J
Va Vb
and
B1 to enter the group programming mode.
Va
: indicates tens (if On = group No. > 10)
Vb
: indicates units
OREV
ON
ON (1)
OFF (0)
1 2 3 4 5 6 7 8
LSB
(11111111 binary = 255 decimal)
indicator lights will flash alternately
B1
is pressed ; from n° 1 to n°16,
B2 (or the «On/Off» button if used).
= cursor
MSB
