130 kg
max.
45 kg
min.
GB

Seat functions and operation

Weight adjustment

The seat must be adjusted for the respective
driver's weight with the driver is sitting on the
seat. Fold back the weight adjustment lever
completely as far as the stop, hold it at the front
and move it upwards or downwards
(10 movements from minimum to maximum).
Before every new movement, bring the weight
adjustment lever back to the medium initial po-
sition (audible locking click). The driver's weight
has been set correctly when the arrow is in the
middle of the indicator window (weight indica-
tion).
Note:
To ensure that the lever for weight adjustment
is accessible and the weight indication can be
seen, the foldable part of the seat cushion must
be folded up / backwards.
Attention:
Do not use the part of the seat cushion which is
folded up / backwards as a seat while driving.
If you do so, there is an increased risk of inju-
ry due to the seat cushion part folding forwards.
To prevent damage to the health and mate-
rial, the individual weight adjustment to the driv-
er's weight must be made and checked before
the boat is driven.
When the minimum / maximum weight ad-
justment has been reached, you can notice an
idle stroke of the lever.
When you have adjusted the weight, fold
the lever from its center initial position com-
pletely until it is locked.
In doing so, do not push the weight adjustment
lever up or down.
Weight adjustment from 45 kg to 130 kg
possible. The technical specifications on the of-
fer drawing are decisive..
27
