4.5 - Legend control unit operation
LED STATUS
FLASHING
2 s
SLOW
FLASHING
1 s
FAST
FLASHING
0.5 s
VERY FAST
N.B: It is not possible to access the configuration menu with the automation in motion.
T HE AUTOMATION MUST BE CLOSED!
4.6 - Selection of operating mode - DIP8
OPERATING MODE
Set to ON for operation on SLIDING GATE motor or set to OFF for operation on
ROLLING SHUTTER
5 - ROLLING SHUTTER FUNCTIONS
5.1 - Learning of transmitters
After a total cancellation of the transmitters, the first taught
transmitter sets the Rolling Code or Fixed Code mode for all the
STEP-BY-STEP FUNCTION LEARNING:
Press and hold P2 until the DL6 LED slowly flashes
orange, release. Activate the transmitter to undergo
learning until the DL6 LED turns green.
(LED DL6 orange reception error, LED DL6 red memory
full - 250 buttons). The SBS function does not work if
DIP8=OFF and DIP7=ON.
SINGLE BUTTON CANCELLATION:
Press and hold P2 until the DL6 LED slowly flashes
orange, do not release, wait for rapid flashing, do not
release, wait for very rapid flashing. Activate the button to
be deleted until the DL6 LED turns green (if the reception
error is orange)
TRANSMITTER TOTAL CANCELLATION:
Turn on the appliance by holding down P2 until the DL6
LED quickly flashes orange, do not release, wait for
green flashing. All transmitters cancelled.
5.2 - Man present function
Press P1 and P2 simultaneously until the DL6 LED turns
red. P1 opens man present, P2 closes man present.
Press P1 and P2 simultaneously to exit the mode.
CONTROL UNIT KEYS
PRESS
HOLD PRESSED
3s
P1
P2
P1
other transmitters.
P2
2 s
3s
FLASHING -
SLOW
ORANGE
P2
3s
P2
3s
ON
RED
P1 + P2
TRANSMITTER
3s
P2
OFF
ROLLING
SHUTTER
2 s
3s
FLASHING -
SLOW
ORANGE
1 s
0.5 s
FLASHING -
FLASHINGVERY
FAST
FAST
ORANGE
ORANGE
2 s
1 s
FLASHING -
FLASHING -
SLOW
FAST
ORANGE
ORANGE
3s
P1
P2
ON
SLIDING GATE
3s
ON
GREEN
3s
ON
GREEN
2 s
FLASHING -
SLOW
GREEN
3s
3s
P1 + P2
EN
21
