4.2 - Table of connections

CONNECTIONS TERMINAL BOARD 1
Safety earth
L Power supply phase 230Vac 50-60 Hz
N Power supply neutral 230Vac 50-60 Hz
L1 Close motor phase
L2 Open motor phase
COM Common motor
FLASH Flashing / 230Vac courtesy light
CONNECTIONS TERMINAL BOARD 2
+P OUT Gate open light output or photo devices test output (Set DIP4)
+24 V Non-regulated 24Vdc output positive
-24 V Non-regulated 24Vdc output negative
NC contact (closure) photocells between PH1 and COM. The photocell intervenes at any time during closing of the
PH1
automation causing immediate stopping of motion, reversing the direction of travel
If DIP5 = OFF ► Input STOP (NC)
STOP If DIP5 = ON ► Input 8K2 Safety edge:
8K2 intervenes during opening and closing with a brief inversion of motion
COM Common for inputs PH1, STOP, SBS, OPEN, CLOSE (GND)
NA contact OPENING command between OPEN and COM
OPEN MAN PRESENT function contact. The gate OPENS as long as the contact is being pressed
With DIP8 = ON ► opening limit switch
NA contact CLOSURE command between CLOSE and COM
CLOSE MAN PRESENT function contact. The gate CLOSES as long as the contact is being pressed
With DIP8 = ON ► closure limit switch
NA contact STEP-BY-STEP command between SBS and COM
SEQ
Open/Stop/Close/Stop command
COM Common for inputs PH1, STOP, SBS, OPEN, CLOSE
M3 Terminal for antenna / GND
4.3 - DIP-Switch Table
DIP Function
1 Automatic reclosure
2 SEQ Operation (SBS)
3 Condominium
4 Output P.OUT
5 Input STOP
6 Output FLASH
7 Man present (if ROLLING SHUTTER)
7 Slowing speed (if SLIDING GATE)
8 Mode

4.4 - TRIMMER table

BUTTON Function
TR1 Pause Time 1 - 125 Sec.
TR2 Motor force (if SLIDING GATE) Courtesy light time 10 - 300 Sec. (if ROLLING SHUTTER)
20
OFF
Not Enabled
Step by Step
Not Enabled
Light
STOP (N.C.)
Flashing light
Not Enabled
Low
ROLLING SHUTTER
ON
Enabled
Open - Close
Enabled
Safety devices testing
Safety (8k2)
Courtesy light
Enabled
High
SLIDING GATE
