1. Engine shut-off cord (lanyard)
2. Clip
3. Engine shut-off switch
EMU26092

Main switch

The main switch controls the ignition system;
its operation is described below.
 "
" (off)
With the main switch in the "
tion, the electrical circuits are off, and the key
can be removed.
 "
" (on)
With the main switch in the "
the electrical circuits are on, and the key can-
not be removed.
 "
" (start)
With the main switch in the "
sition, the starter motor turns to start the en-
gine. When the key is released, it returns
automatically to the "
ON ON
OFF START OFF START
3
2
1
ZMU05818
" (off) posi-
" (on) position,
" (start) po-
" (on) position.
OFF
ON
OFF START
EMU32054
Power trim and tilt switch on remote
control
The power trim and tilt system adjusts the
outboard motor angle in relation to the tran-
som. Pushing the switch "
outboard motor up, and then tilts it up. Push-
ing the switch " " (down) tilts the outboard
motor down and trims it down. When the
switch is released, the outboard motor will
stop in its current position. For instructions
on using the power trim and tilt switch, see
pages 68 and 70.
Components
ON
START
ZMU04567
ON
OFF START
ZMU05821
" (up) trims the
