KNOW YOUR BRUSH CUTTER
The safe use of this product requires an understanding of the information on the product and in this
Operator's Manual as well as knowledge of the project you are attempting. Before use of this product,
familiarize yourself with all operating features and safety rules.
Components
1. Primer Bulb
2. Fuel Tank Cap
3. Fuel Tank
4. Air Filter Knob
5. Choke Lever
6. Main Handle
7. Stop Switch
8. Battery Release Button
9. Battery Slot
10. Guard Handle
11. Locking Pin
12. Shaft
13. Debris Guard
14. Trimming Line Cutting Blade
15. Safety Nut
16. Pressure Plate Cover
17. Pressure Plate
18. Brush Cutter Blade
19. Locking Knob
32
34
35
20. Shaft Connection Sleeve
21. Assist Loop Handle
22. Start Button
23. Battery Power Indicator
24. Throttle Safety
25. Spark Plug Cover
26. Throttle Lever
28. Rear Cover Housing
29. Engine Housing
30. Start Button Cover
31. Shoulder Strap Clasp
32. Blade Cover
33. Shoulder Strap
34. Charging Port
35. Battery Pack
36. Charger
37. Charging Connector
