6. Loosen the locking screw for
the trailing shield on both sides;
remove the worn trailing shield
(Fig. 35).
7. Replace with a new trailing shield
and attach it with the two locking
screws and flat washers.
8. Re-install the rear wheel covers
and rear wheels; be sure to
replace the parts in the exact
order in which they were
removed (Fig. 36).
STORING THE MOWER
The following steps should be taken in
order to prepare the lawn mower for
storage.
1. Remove the battery pack from
the mower and store it at room
temperature in a dry location.
2. Clean the mower as described earlier in the maintenance section.
3. Inspect the blade and replace it or sharpen it if required.
4. Lubricate the mower.
5. Store the mower in a dry, clean location. Do not store it next to corrosive
materials, such as fertilizer or rock salt.
6. Store the mower in a covered, enclosed space, that is cool and dry and out of the
reach of children.
7. Do not cover the lawn mower with a solid plastic sheet. Plastic coverings trap
moisture around the mower, which causes rust and corrosion.
44
56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC
35
Locking Screw For
Trailing Shield
36
Wheel
Axle
Trailing shield
Dust Cover
Bolt
Rear Wheel
Wave Washer
Wheel Cover Locking Screw
Wheel Cover
