Wiring Diagram - GE RARWT Manuel Du Propriétaire Et Instructions D'installation

Wiring Diagrams
Table 1: terminals for three wires 1-stage heat / 1-stage
cool system.
Smart Wall Thermostat
(RARWT_ _)
Heat-Pump
Only
49-5000400 Rev. 5
ON
4 DIP
Switches
OFF
Auto Gen Furnace
Relay Relay
RAREC_ _
DIP Switches
RV-C Control
Only (RAREC1A)
RARWT_ _ DIP Switches
#1 select between Cool Only
and Heat-Pump
#2 is not used
#3 is not used
#4 used to disable Furnace
Mode selection.
This is for installs where a
furnace is not connected to
the RVAC control.
Direct Wire Control
Only (RAREC2A)
8 7 6 5 4 3 2 1
5A
FUSE
Fan 3 Fan 2 / Fan 1
Relay HP RV Relay
BL OR YE RD WH GR
3.
1. 2. 4. 5.
6.
BK
L i n e
Comp.
Relay
WH
GR
+12V from Supply
red
0 V from Supply
black / white
RV-C Pin-Out
Only (RAREC1A)
13
