Minicap FTC 262
Safety notes for the installation in explosion hazardous areas:
1) Install according to the manufacturer's instructions and other valid standards and guidelines.
2) Observe the installation and safety instructions.
3) The level detector must not be operated outside of its electrical, thermal and mechanical
performance limits.
4) The intrinsically safe signal circuit is grounded: for this reason potentials must be equalised
along the route of the cable (inside and outside of the explosion hazardous area).
5) After mounting and connecting the sensor, check that a degree of protection of at least IP 66
to EN 60529 has been attained (screw lid tight, mount cable glands correctly).
Performance limits:
Electrical performance limits
Type FTC 262-Bxx4xx (AC/DC relay version)
Operating voltage
Current consumption
Relay circuit
Fuse
Type FTC 262-Bxx2xx (DC pnp version)
Operating voltage
Current consumption
Switch output (PNP)
Current
Switching capacity
Thermal performance limits
Maximum surface temperature T of the sensor
(Category 1 D) at an ambient temperature of 40 °C
Maximum surface temperature T of the sensor
(Category 1 D) at an ambient temperature of 80 °C
Permissible process temperature in Zone 20
Maximum surface temperature T of the electronics housing
(Category 3 D) at an ambient temperature of 40 °C
Maximum surface temperature T of the electronics housing
(Category 3 D) at an ambient temperature of 60 °C
Permissible ambient temperature in Zone 22
Degree of ingress protection to EN 60529:
Ingress protection of sensor (Category 1 D)
Ingress protection of electronics housing (Category 3 D)
Mechanical performance limits
Maximum pull-down forces on rope at room temperature
and at –40 °C
Maximum pull-down forces on rope at 80 °C
Endress+Hauser
AC 20...253 V, 50/60 Hz or
DC 20...55 V
max. 2 W
AC 253 V / 4 A / 1000 VA or
DC 253 V / 0,2 A / 50 W or
DC 30 V / 4 A / 120 W
500 mA
DC 10,8...45 V
max. 1,5 W
max. 200 mA
9 W
57 °C
97 °C
–40 °C...+80 °C
57 °C
77 °C
–40 °C...+60 °C
IP 66
IP 66
3000 N
2800 N
F
N
3000
2800
–40 0 +40 +80
XA 092F-A
T
2
°C
en
