To Stop
Release the trigger.
NOTICE:
The motor runs only when the lock-off button
and trigger are both pressed.
Speed Adjustment Function (Fig. M)
The line trimmer has two speeds. Position"1" is for low
speed while Position "2" for high speed.
M-1 High/low-Speed Switch
M-2 Lock-Off Button
M-3 Trigger
USING THE LINE TRIMMER
Clear the area to be cut before each use. Remove all
objects, such as rocks, broken glass, nails, wire, or line,
that can be thrown or become entangled in the cutting
attachment. Clear the area of children, bystanders,
and pets. At a minimum, keep all children, bystanders
and pets at least 15m away; there still may be risk to
bystanders from thrown objects. Bystanders should be
encouraged to wear eye protection. If you are approached,
stop the motor and cutting attachment immediately.
Before each use, check for damage/worn parts
Check the bump head, guard and front-assist handle
and replace the parts that are cracked, warped, bent, or
damaged in any away.
The line-cutting blade on the edge of the guard can dull
over time. It is recommended that you periodically
sharpen with a file or replace it with a new blade.
After each use, clean the trimmer.
ADJUSTING CUTTING LINE LENGTH
The trimmer head allows the operator to release more
cutting line without stopping the motor. As line becomes
frayed or worn, additional line can be released by lightly
tapping the trimmer head on the ground while operating
the trimmer (Fig. Q).
NOTICE:
Line release will become more difficult as the
cutting line becomes shorter.
WARNING:
Do not remove or alter the line cutting
blade assembly. Excessive line length will cause the motor
to overheat and may result in serious personal injury.
LINE REPLACEMENT
NOTICE: Always use the recommended nylon cutting
line with a diameter that does not exceed 2.4 mm.
Using line other than that specified may cause the
line trimmer to overheat or become damaged.
WARNING: Never use metal-reinforced line,
wire, or rope, etc. These can break off and become
dangerous projectiles.
1. Remove the battery pack.
2. Remove the remaining cutting line, if necessary.
3. Cut 4m long cutting line, Insert the line into the
mounting hole inside the eyelet (Fig. R). Push and pull
the line from the other side until equal amounts of
line appear on both sides of the spool.
4. Press, while rotating the lower cover assembly in the
arrow direction, to wind the line onto the spool until
approximately 14cm of line is showing on each side
(Fig. S).
5. Push the lower cover assembly down while pulling on
the lines to manually advance the line and to check
for proper assembly of the trimmer head.
When the cutting line breaks from the line outlet or the
cutting line is not released when the trimmer head is
tapped, follow the steps below:
1. Press the release tabs on the upper cover and
remove the lower cover assembly by pulling it
straight out (Fig. T & U).
2. Remove the cutting line from the spool .
3. With one hand holding the lower cover assembly, use
the other hand to grasp the lower cover assembly
and align the tabs on the upper cover with the holes
in the lower cover assembly (Fig. V); Use your palm
to press the lower cover assembly until the tabs lock
with the upper cover.
4. Follow the instructions in "LINE REPLACEMENT" to
reload the cutting line.
3-TEETH BLADE REPLACEMENT
1. Remove the lower cover assembly as Fig. T & U
2. Insert the stabilizer then use an impact socket
wrench to loosen the nut as Fig. X1 & X2.
3. Remove all parts except inner flange and nut
(Fig. X3), mount the blade onto the motor shaft as
fig. X4.
4. Tighten the blade as Fig. X5.
