Features and Specifications
Standard Features
80" Sleep Surface
Travel Range: 7" to 30"
Locking System:
• Roll-in-Low Lock System
• Care-Lock Roll at any Height Mobility
Pendant Jacks on both left and right side
Whisper Quiet DC Motors
Welded Tubular Frame
Grid Sleep Surface
SoftTone Frame Color
Baseboard Bumper
Wide Stable Base
Heavy-Duty Casters
Mattress Stops
Patented Lifting Mechanism (US Patent 6473922)
EasyLift Leg Positioner
Battery Pack Cable
Electrical Specifications
Power: 120 VAC
Frequency: 60 Hz
Current Rating: 4.0 Amps (120V)
Classification: Class I, Type B or Class II, Type B
Mode of Operation: 10% Maximum Duty Cycle
2 minutes on/18 minutes off
Circuit Protection: Auto Reset Current Sensor
Environmental Conditions
Operating Conditions:
Ambient Temperature: +10°C to +40°C
Relative Humidity: 30% to 75% Non-Condensing
Atmospheric Pressure: 700 hPa to 1060 hPa
Storage and Shipping Conditions:
Ambient Temperature: -40°C to +70°C Relative
Humidity: 10% to 100%
Atmospheric Pressure: 500 hPa to 1060 hPa
I.D. Label Symbol Definition
Attention
Consult accompanying documents
Safe Working Load
Type B Applied Parts, user controls, mattress,
support platform
Class II Equipment
Protective Earth (ground)
Accessories And Options
80" and 84" Joerns Mattresses
®
Joerns Bed Panels
F18 SoftCare ½ Length Assist Device Set
F14SC Assist Device Set
F025 Assist Handle
F026 Assist Device
F028 Deluxe Assist Device
Staff Control
IV Rod
Floor Mat
Emergency Battery Backup System
• Battery Backup 24V
• Battery Charger 24V
• Wall Mounting Bracket for Charger
Trapeze and Trapeze Adapter
Drainage Bag Holder
Bed Identification Numbers
When ordering parts or when contacting our Customer
Care Department, please include the bed's model,
product and serial numbers, found on the identification
labels. The identification labels are located on bed
frame under the sleep deck foot section.
Conforms To:
AAMI STD ES60601-1
IEC STD 60601-1
IEC STD 60601-2-52
Certified To CSA STD C22.2 # 60601-1
Mechanical Specifications
Description:
80" ......................................84.25"L x 35.0"W x 7.65"H
Weight
Roll-in-Low .................................... 220 lbs. (99.8 kg)
Roll at any Height ........................ 230 lbs. (104.3 kg)
Care-Fit Integrated Width ................. +40 lbs. (18.1 kg)
Maximum Back Angle .........................65° to horizontal
Maximum Knee Angle ........................35° to horizontal
Maximum Knee To Leg Angle ................................. 45°
Minimum Height Mattress Support Surface
Roll-in-Low ........................................................7.00"
Roll at any Height ..............................................7.65"
Maximum Height Mattress Support Surface
Roll-in-Low ......................................................30.00"
Roll at any Height ............................................30.65"
Hi-Lo Speed
Unloaded .................................................50 seconds
With 200 lbs ............................................52 seconds
Tolerance ± 3 seconds
Safe Working Load ............................ 600 lbs. (272 kg)
Maximum Patient Weight ................... 550 lbs. (249 kg)
Joerns® Bed Frames
EasyCare®
Dimensions:
© 2020 Joerns Healthcare • 6110345 RevC • 20-2535
5
