RRH 04P-01
For safer use – please note
• Check regularly that the retainer is fully screwed
on to the cylinder.
• If different RRH 04/06/08P models are in use at
the same workplace all 1.7 mm wire retainers
(black) shall be withdrawn and replaced by 2.0
mm wire retainers (yellow) on all hammers. This
is due of safety reasons, i.e. to prevent mixing up
the retainers and using the wrong type on the
wrong hammer model.
A
This machine does not satisfy the normal re-
quirements for use in explosive environment
as the machine casing contains aluminium.

General information

EC DECLARATION OF CONFORMITY
We, Atlas Copco Industrial Technique AB, S-105
23 STOCKHOLM, SWEDEN declare that the
product (with name, type and serial number, see front
page) is in conformity with the following Direct-
ive(s):
2006/42/EC
Harmonised standards applied:
ISO 11148-4
Technical file available from:
Quality Manager, Atlas Copco Industrial Technique,
Stockholm, Sweden
Stockholm, 1 July 2013
Tobias Hahn, Managing Director
Signature of issuer
Installation
Installation
• Fit the support handle in suitable position for
right- or left hand operation respectively.
• Always make sure that you have the correct guard
for the grinding equipment.
• Attach the grinding equipment.
Adjust the guard for best operator protection.
• Connect the machine to the air line.
Blow out the hose before connecting.
The motor requires no additional lubrication dur-
ing operation.
• The throttle valve lever may only be activated
after pushing the lever catch release arm forwards.
EN
© Atlas Copco Industrial Technique AB - 9836 9751 00
Safety and operating instructions
A
Check regularly that the catch and the release
arm moves easily.
Installation of vibrating tools
It is recommended that a minimum length of 300
mm of flexible hose for compressed air is inserted
between a vibrating tool and the quick-action coup-
ling.
Air quality
• For optimum performance and maximum machine
life we recommend the use of compressed air with
a maximum dew point of +10°C. We also recom-
mend the installation of an Atlas Copco refrigera-
tion-type air dryer.
• Use a separate air filter of type Atlas Copco FIL.
This filter removes solid particles larger than 15
microns and also removes more than 90 % of li-
quid water. The filter must be installed as close
as possible to the machine/equipment and prior
to any other air preparation unit such as REG or
DIM (please see Air Line Accessories in our main
catalogue). Blow out the hose before connecting.
Models which need air lubrication:
• The compressed air must contain a small quantity
of oil.
We strongly recommend that you install an Atlas
Copco oil-fog lubricator (DIM). This should be
set according to air consumption by the air line
tool according to the following formula:
L = Air consumption (litre/s).
(May be found in our sales literature).
D = Number of drops per min (1 drop = 15 mm
L* 0.2 = D
this applies to the use of long work cycle air line
tools. A single point lubricator type Atlas Copco
Dosol can also be used for tools with short running
cycles.
Information about Dosol settings may be found
under Air Line Accessories in our main catalogue.
Lubrication-free models:
• In the case of lubrication-free tools it is up to the
customer to decide on the peripheral equipment
to be used. However, it is no disadvantage if the
compressed air contains a small quantity of oil
e.g. supplied from a fog lubricator (DIM) or Dosol
system.
• Note – This does not apply to turbine tools, which
should be kept oil free.
Compressed air connection
• The machine is designed for a working pressure
of 6–7 bar = 600–700 kPa = 87–102 psi.
• Blow out the hose before connecting.
