AC power connection
HT-SB200
ENGLISH
After checking all the connections have been made correctly,
connect the AC power lead to the AC power input socket, then
to the wall socket.
Using with the AC/DC adaptor
1
Plug the AC power lead into the AC/DC adaptor.
2
Plug the AC/DC adaptor cable into the DC IN socket
on the speaker.
3
Plug the AC power lead into a wall socket. The
STAND-BY indicator will turn RED when AC power is
applied. The power indicator will turn GREEN when
the system in "ON".
AC/DC Adaptor Cable
Wall socket
(AC 100 - 240 V ~ 50/60 Hz)
Notes:
Unplug the AC/DC adaptor from the wall socket if the speaker
will not be used for a long period of time.
Use only the supplied AC/DC adaptor. Using other AC/DC
adaptor may cause an electric shock or fire.
E-11
2
DC IN socket
LINE IN 2
(DC 12V)
AC power lead
1
3
AC/DC Adaptor
Remote control
Battery installation
1
Insert pin into the hole as shown and pull to open the
battery holder.
2
Remove the old battery from the battery holder, insert
the new battery and then slide the battery holder back
into the remote control.
Battery holder
RIGHT
LEFT
DC
LINE IN 1
Polarity (+) symbol
Precautions for battery use:
Remove the battery if the speaker will not be used for a long
period of time. This will prevent potential damage due to
battery leakage.
Back of
remote control
Battery type
Locking tab
Pin
Positive (+) side up
