Installation
5
7. Tighten the outer two screws to the top of the
microwave oven. (While tightening screws, hold
the microwave oven in place against the wall
and the top cabinet.)
8. Install grease filters. See the Owner's Manual
packed with the microwave.
5.2.3 Recirculating (non-vented
ductless type C)
3/8" TO EDGE
12"
TO
NOTE: IT IS VERY IMPORTANT
READ AND FOLLOW THE DIRECTIONS
INSTRUCTIONS
IN THE INSTALLATION
BEFORE PROCEEDING WITH THIS
REAR WALL TEMPLATE. 4"
This Rear Wall Template serves to position the bottom
mounting plate and to locate the horizontal exhaust
outlet. that the template is positioned
1. Use a level to check
accurately. one stud on the left or
2. Locate and mark at least
right side of the centerline.
It is important to use at least one wood
a stud to support the weight
screw mounted firmly in two additional, evenly spaced
of the microwave. Mark
locations for the supplied toggle bolts. is
3. Drill holes in the marked locations. Where there
a stud, drill a 3/16" hole for wood screws. For holes
that do not line up with a stud, drill 5/8" holes for
toggle bolts. MOUNTING PLATE
DO NOT INSTALL THE
AT THIS TIME.
4. Remove the template from the rear wall.
Instruction book for your
5. Review the Installation
installation situation.
para consultar la
Darle vuelta a la hoja
versión en Español.
to align with holes in the
Locate and mark holes
mounting plate.
IMPORTANT: STUD ON EITHER SIDE OF
LOCATE AT LEAST ONE
THE CENTERLINE. EVENLY
MARK THE LOCATION FOR 2 ADDITIONAL,
IN THE MOUNTING PLATE
SPACED TOGGLE BOLTS
AREA.
along the dotted line.
Trim the rear wall template
Installation overview
C1. Attach Mounting Plate to Wall
C2. Prepare Top Cabinet
C3. Check Blower Plate
C4. Mount the Microwave Oven
C5. Install or change Charcoal Filter
28 / 63 EN
along the dotted line.
Trim the rear wall template
to align with holes in the
Locate and mark holes
mounting plate.
IMPORTANT: OF
LOCATE AT LEAST ONE STUD ON EITHER SIDE
THE CENTERLINE. FOR 2 ADDITIONAL, EVENLY
MARK THE LOCATION
IN THE MOUNTING PLATE
SPACED TOGGLE BOLTS
AREA.
Over The Range Convection Microwave Oven / Installation Manual
Make sure the screws for the blower
A
motor and blower plate are securely
tightened when they are reinstalled.
This will help to prevent excessive
vibration.
