Installation
5
A
If filler blocks are not used, case
damage may occur from overtight-
ening screws.
1. Lift microwave, tilt it forward, and hook slots
at back bottom edge onto four lower tabs of
mounting plate.
When mounting the microwave
C
oven, thread power cord through
hole in bottom of top cabinet. Keep
it tight throughout Steps 1–3. Do not
pinch cord or lift oven by pulling cord.
2
2. Rotate front of oven up against cabinet bottom.
3. Insert a self-aligning screw through top center
cabinet hole. Temporarily secure the oven by
turning the screw at least two full turns after
the threads have engaged. (It will be completely
tightened later.) Be sure to keep power cord
tight. Be careful not to pinch the cord, especially
when mounting flush to bottom of cabinet.
Over The Range Convection Microwave Oven / Installation Manual
4. Attach the microwave oven to the top cabinet.
Cabinet Front
5. Insert 2 self-aligning screws through outer top
cabinet holes. Turn two full turns on each screw.
1
6. Tighten center screw completely.
Cabinet Bottom Shelf
Filler Block
Self-Aligning Screw
Microwave Oven Top
5
6
Equivalent
to Depth
of Cabinet
Recess
27 / 63 EN
