Original operating manual
1 Symbols ................................................
2 Items included......................................
3 Technical data ......................................
4 Intended use.........................................
5 Safety instructions ...............................
6 Assembly ..............................................
7 Power supply and start-up...................
8 Settings.................................................
9 Working with the machine ...................
10 Service and maintenance.....................
11 Environment .........................................
12 EU Declaration of Conformity ..............
The illustrations specified are located at the begin-
ning and end of the operating manual.
1 Symbols
Warning of general danger
Risk of electric shock
Read the Operating Instructions/Notes!
2

Items included

[1-1] Cutting depth adjuster
Flange bolt
[1-2]
Scales/rulers
[1-3]
[1-4] Retaining panel for portable circular saws
Protective cover
[1-5]
Protective cover bracket
[1-6]
[1-7] Push stick
Preset profile setting rail
[1-8]
3

Technical data

Module mounting / retaining
panel
Inclination
Cutting depth at 0°
Cutting depth at 45°
Weight
4

Intended use

The following Festool plunge-cut saws can be in-
stalled in the CMS-TS-55-R retaining panel:
- TS 55 REBQ, TS 55 REQ, TS 55 RQ
The installation of other portable circular saws is
not possible and therefore not permitted.
11
Fit one of the above-mentioned portable circular
11
saws to the retaining panel and install it in the
11 CMS-GE to form a mobile bench-mounted circular
saw.
11
Circular saws are intended to be used for sawing
11
wood, materials similar to wood, plaster and ce-
12
ment-bonded fibre materials and plastics. When
13
fitted with special saw blades for aluminium of-
fered by Festool, these machines can also be used
13
for sawing aluminium.
14
14
14
The user will be liable for damage due to improp-
14
er use.
5
5.1
stand and the power tool to be mounted. Failure to
follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future ref-
erence.
The term "power tool" in the warnings refers to
your mains-operated (corded) power tool or bat-
tery-operated (cordless) power tool.
- Keep all of the attached documents and pass on
the documentation if the machine changes own-
ership.
- Disconnect the plug from the power source and/
or the battery pack from the power tool before
making any adjustments or changing accesso-
ries. Accidental starting of the power tool is a
cause of some accidents.
- Properly assemble the working stand before
mounting the tool. Proper assembly is important
to prevent risk of collapse.
CMS-TS-55-R
- Securely fasten the power tool to the working
stand before use. Power tool shifting on the
working stand can cause loss of control.
0° to 45°
- Place the working stand on a solid, flat and level
0 - 51 mm
surface. When the working stand can shift or
0 - 38 mm
rock, the power tool or workpiece cannot be
3,3 kg
steadily and safely controlled.
- Do not overload the working stand or use as lad-
der or scaffolding. Overloading or standing on
the working stand causes the stand to be "top-
heavy" and likely to tip over.
WARNING
Safety instructions

General safety instructions

WARNING Read all safety warnings and all
instructions provided with the working
CMS-TS-55-R
GB
11
