Power input
Prise d'alimentation /Toma de alimentación
Netzbuchse / 电源
Phono input
Entrée phono / Entrada de fono
Phono eingang / 输入端
Line inputs (4)
Entrées line / Entradas de linea
Hochpegel eingang / 输入端
Power Supply
Voltage: 230V or 115V
Frequency: 60 or 50Hz
Power Consumption: 250W
230V Fuse: T3.15AL 20mm
115V Fuse: T5AL 20mm
*Full product details and specifications available at www.rega.co.uk
• This unit can become hot. Always allow adequate air circulation.
• Never cover any part of the amplifier.
• Never expose the unit to rain or moisture.
• Do not open the case covers. There are no user serviceable parts inside.
• This unit is intended for use in moderate climates.
• Always turn off the amplifier when changing leads or speaker cables.
Set-up
Specifications
Inputs
Phono input sensitivity: 1.7mV (47KΩ // 220pF)
Phono maximum input level: 100mV
Line input sensitivity: 164mV (40KΩ)
Line maximum input level: 10V
Made in England
Speaker outputs (2)
Sorties enceinte / Salidas altavoz
Lautsprecher ausgang / 音频输出端
Pre-amp output
Sortie pré-ampli / Salida pre-amplificador
Vorverstärker ausgang / 出端
Record output
Sortie enregistrement / Salida de grabación
Monitor ausgang / 註冊出端
Speakers output power: 90W (6Ω)
Record output level: 164mV
Record output impedance: 470Ω
Pre-amp output level: 625mV
Pre-amp output impedance: 600Ω
Outputs
