Installation

See Figures 1-10.
The images shown are purely indicative. Their
purpose is to illustrate the main assembly steps for
the entire range.
IMPORTANT: See the "Wiring Diagrams" paragraph
to check the 3 ventilation speeds.
Fig. 8 CAUTION: use the outer opening of the cover
only for the passage of a 16 mm diameter tube
coming from the fixed system.

Wiring diagrams

See Figure 11A.
Connection with the optional device upon request is
foreseen to check ventilation speeds (device not
supplied in packaging):
- 11A) Vortice 3-speed selector Code 12.869
IMPORTANT
Vortice guarantees correct product operation and
control only when paired with the Vortice 3-speed
selector (Code 12.869).
Other types of connection
Alternatively, other connection diagrams are
available, associated to different control modes
(devices provided by the installer).
Connection alternative for new installation
- 11B) Pairing with 3-switch control
- 11C) Pairing with Electronic dimmer
Machine replacement on existing system
Connection without modifications to the electrical
system: the same switches as on the existing system
will be used. CAUTION: it will not be possible to
connect all 3 available speeds but only those for
which the electrical system is set up (to be chosen by
the installer):
- 11D) Speed connection: Minimum and Maximum
- 11E) Speed connection: Medium and Maximum.
CAUTION
Correct operation of ERP 2018 is only guaranteed
when set in compliance with the connection diagram
11A).
